Wire Harness Quality Detection AX7900 Electronics Unicomp X Ray Equipment
Description of IC X-Ray machine AX7900:
Widely applied for BGA, CSP, PCB, Flip Chip, LED, Fuse, Diode, Semiconductor, Battery Industry, Small Metal Casting,
Electronic Connector Module, Cables, Aerospace Components, Photovoltaic Industry, etc.
APPLICATION of IC Xray machine AX7900:
FEATURES of IC Xray machine AX7900:
Technical Specifications of AX7900
| Item | Definition | Specs |
| System Summary | Footprint | 1200(W)×1200(D)×1530(H)mm |
| Machine Weight | 1120 kg |
| Plywood Packing Size | 1800(W)×1400(D)×1800(H)mm |
| Power Supply | AC 110/220V, 50/60Hz |
| Packing Weight | 1330 kg |
| Power Consumption | 1.0 kW |
| X-ray Tube | Tube Type | Sealed |
| Voltage | 0~90kV (Adjustable) |
| Max.Power | 8W |
| Focus Spot Size | 5μm |
| Imaging System | Detector | Flat Panel Detector (FPD) |
| Effective Detection Area | 130*130mm |
| Pixel Matrix | 1536*1536mm |
| Pixel Size | 85μm |
| Frame Rates | 20fps |
| System Magnification | 600X |
| Software | Auto-measuring | BGA Soldering Voids Auto-measuring and Support Data/Graphic Output |
| Multiple Measuring Tools | Support Measuring Distance, Angle, Diameter, Polygon, PTH filling rate, etc. |
| CNC Mode | CNC Programmable Inspection, Easy Operation and User Friendly |
| Real-time Display | Real-time Displaying the Working Data of Voltage, Current, Angle, Date, etc |
| Navigation | Convenient Target Point Positioning System |
| Motion Control System | Movement Control | Joystick, Keypad & Mouse |
| Max. Loading Area/Weight | 520*420mm / 10kg |
| Max. Inspection Area | 460*400mm |
| Tilting Angle | ±25° |
| Manipulator | 5-axis with X / Y / Z1 / Z2 / T |
| Industrial PC | Monitor | 24’’ FHD LCD Display |
| System OS | Windows 10 64bit |
| Hard disk | 1TB |
| RAM | 4GB |
| CPU model | Intel i7 Processor |
| Other Features | Energy Saving | X-Ray Auto-off when it's out of work over than 5 minutes |
| Authority Management | Fingerprint Access Management System, and Support Password Accessing |
| X-Ray Safety | <1μSv/h (Meets All International Standards) |
| Safety Operation | Electromagnetic Interlock, Warning Light and Real-time Radiation Leakage Monitor |
Inspection Images of IC X-Ray machine AX7900:
